AirFiber X 5 GHz, 34 dBi, Slant 45 | AF-5G34-S45 Price in Pakistan

What Is airFiber X 5 GHz, 34 dBi, Slant 45 | AF-5G34-S45?

The airFiber X 5 GHz, 34 dBi, Slant 45 | AF-5G34-S45 is a professional high-gain directional antenna designed for long-range wireless communication and point-to-point network backhaul. It is built for ISPs, WISPs, telecom operators, businesses, and network professionals who need a focused and reliable wireless connection between two fixed locations.

The Ubiquiti AF-5G34-S45 operates in the 5 GHz range and provides 34 dBi gain. Its large 1050 mm reflector and narrow beam help concentrate the wireless signal toward a specific destination. The antenna uses dual-linear ±45° slant polarization, making it suitable for compatible airFiber X radio systems.

Unlike a standard WiFi access point, this product is designed for dedicated outdoor wireless links. It can be used to connect towers, offices, warehouses, campuses, remote sites, and other network locations where installing fiber is difficult or expensive.

AF-5G34-S45 Key Features

The AF-5G34-S45 offers a combination of high gain, directional performance, and professional outdoor construction.

Ubiquiti AF-5G34-S45 Main Features

• 5 GHz high-gain directional antenna
• 34 dBi antenna gain
• 5.1–5.8 GHz frequency range
• Dual-linear ±45° slant polarization
• Approximately 3° beamwidth
• 42 dB front-to-back ratio
• 35 dB minimum cross-polarization isolation
• 1050 mm reflector
• Universal pole mounting
• airFiber X radio mounting bracket
• Weatherproof RF jumpers
• Up to 200 km/h wind survivability
• Designed for long-range point-to-point links
• Suitable for ISP and WISP backhaul
• Professional outdoor wireless infrastructure

AF-5G34-S45 Specifications

The following AF-5G34-S45 specs provide the main technical details of this professional antenna.

AF-5G34-S45 34 dBi High-Gain Antenna

The 34 dBi gain is one of the most important features of the AF-5G34-S45. High antenna gain concentrates RF energy into a focused direction, making the antenna suitable for fixed wireless connections.

The large reflector helps provide the directional performance required for long-distance communication. Instead of broadcasting a signal broadly, the antenna focuses it toward the remote endpoint.

This makes the AF-5G34-S45 34 dBi antenna a practical choice for professional wireless backhaul.

However, antenna gain does not guarantee a specific distance or throughput. Actual performance depends on the connected radio, distance, frequency, channel width, interference, antenna height, line of sight, Fresnel-zone clearance, and local regulations.

airFiber X 5 GHz Slant 45 Polarization

The AF-5G34-S45 Slant 45 uses dual-linear polarization with ±45° slant orientation.

This polarization configuration is designed for compatible airFiber X radios and professional wireless backhaul systems. It can help support dual-polarized wireless communication when the radio and link are configured correctly.

The antenna also provides strong cross-polarization isolation, which is important when maintaining separation between polarization paths.

For best performance, the polarization orientation should be correctly configured at both ends of the wireless link.

AF-5G34-S45 3° Beamwidth

The AF-5G34-S45 features an approximately 3° directional beam.

A narrow beam is useful when connecting two fixed locations because it concentrates the RF signal toward the intended endpoint. It can also reduce unwanted reception from directions outside the main communication path.

However, narrow-beam antennas require careful alignment. Even a small positioning error can reduce signal quality, especially on long-distance wireless links.

For professional deployments, installers should use proper alignment tools and verify signal levels after installation.

AF-5G34-S45 for Point-to-Point Wireless

The AF-5G34-S45 for point-to-point wireless is designed to connect two fixed network locations.

It can be used between:

• Office buildings
• Network towers
• ISP locations
• WISP towers
• Warehouses
• Campuses
• Remote offices
• Data centers
• Rural network sites
• Commercial buildings

A compatible airFiber X radio is installed with the antenna at each end. The antennas are then aligned toward one another to create a focused wireless bridge.

Ubiquiti AF-5G34-S45 for WISP Networks

The Ubiquiti AF-5G34-S45 for WISP networks is suitable for professional wireless backhaul infrastructure.

A WISP can use the antenna to establish a dedicated link between its main network and a remote tower. The remote tower can then distribute internet connectivity to customers using additional wireless access equipment.

This makes the antenna useful for expanding wireless infrastructure without requiring fiber between every network location.

Before deployment, WISP operators should check spectrum availability, interference, antenna height, link distance, Fresnel clearance, and regulatory requirements.

AF-5G34-S45 for Long-Range Backhaul

The AF-5G34-S45 long-range antenna is designed for fixed wireless backhaul applications.

Its combination of 34 dBi gain, narrow beamwidth, and dual polarization makes it suitable for professional connections where directional performance is more important than broad coverage.

A successful long-range link requires more than simply installing two high-gain antennas. The complete link should be planned around:

• Distance
• Antenna gain
• Radio output power
• Frequency
• Channel width
• Signal strength
• Noise level
• RF interference
• Terrain
• Fresnel-zone clearance
• Weather
• Cable losses

A proper link budget should be completed before purchasing equipment for a critical deployment.

AF-5G34-S45 Outdoor Construction

The AF-5G34-S45 is designed for outdoor telecom and networking installations.

Its large 1050 mm reflector provides the required aperture for high-gain directional performance. The complete antenna and mounting system weighs approximately 13.5 kg.

The antenna is designed to withstand wind conditions of up to 200 km/h, making a strong mounting structure essential.

When installing the antenna, the supporting pole or tower should be properly rated for the equipment’s weight and wind loading. Grounding and surge protection should also be considered for outdoor installations.

AF-5G34-S45 Mounting and Installation

The AF-5G34-S45 setup is designed around professional pole and tower installations.

The package includes the reflector, mounting system, radio bracket, and weatherproof RF components required for installation with compatible equipment.

A good installation should include:

1. Select a suitable tower or pole.
2. Confirm the wireless path.
3. Check line of sight.
4. Verify Fresnel-zone clearance.
5. Install the antenna securely.
6. Attach the compatible airFiber X radio.
7. Connect RF cables correctly.
8. Align the antenna toward the remote site.
9. Configure the radio.
10. Test signal and link performance.

Because the antenna has a narrow beam, precise alignment is particularly important.

AF-5G34-S45 Compatibility

The AF-5G34-S45 is designed for use with compatible airFiber X radios.

The antenna includes a dedicated airFiber X radio bracket, allowing the compatible radio to be mounted directly with the dish.

It is important to remember that the AF-5G34-S45 is an antenna and not a complete wireless radio system. The required airFiber radio should be selected separately according to the frequency, capacity, and deployment requirements.

Always verify radio compatibility before purchasing.

Why Buy AF-5G34-S45 in Pakistan?

The AF-5G34-S45 price in Pakistan depends on supplier, availability, warranty, import costs, and market conditions.

If you want to buy AF-5G34-S45 online, it is a strong choice for professional wireless backhaul, ISP networks, WISP infrastructure, and long-range point-to-point connections.

The Ubiquiti AF-5G34-S45 available in Pakistan can help network professionals build high-gain 5 GHz wireless links between fixed locations.

Before purchasing, check the compatibility of your airFiber radio and make sure the intended frequency, transmit power, and antenna configuration comply with applicable regulations.

For more networking equipment, routers, switches, wireless products, and professional IT solutions, visit the IT.BIZ.PK online shop.

Applications of AF-5G34-S45

The airFiber X 5 GHz, 34 dBi, Slant 45 antenna can be used for several professional networking applications.

ISP and WISP Backhaul

Connect network towers and remote distribution locations to a central network using a dedicated wireless link.

Building-to-Building Connectivity

Connect offices, warehouses, campuses, and commercial buildings without installing physical fiber between them.

Tower-to-Tower Links

Create focused wireless connections between telecommunications towers.

Rural Connectivity

Extend network infrastructure to remote locations where fiber deployment is difficult or expensive.

Enterprise Wireless Backhaul

Connect separate business locations and extend a private network between fixed facilities.

Frequently Asked Questions About AF-5G34-S45

What is airFiber X 5 GHz, 34 dBi, Slant 45 | AF-5G34-S45?

The AF-5G34-S45 is a professional 5 GHz, 34 dBi directional antenna designed for long-range point-to-point wireless links and network backhaul.

How much gain does AF-5G34-S45 have?

The Ubiquiti AF-5G34-S45 provides 34 dBi gain, making it suitable for highly directional wireless communication.

What frequency does AF-5G34-S45 support?

The AF-5G34-S45 supports the 5.1–5.8 GHz frequency range.

What does Slant 45 mean on AF-5G34-S45?

Slant 45 refers to the antenna’s ±45° dual-linear polarization configuration. It is designed to work with compatible airFiber X radio equipment.

Is AF-5G34-S45 good for long-range wireless links?

Yes. The AF-5G34-S45 is designed for long-range point-to-point connectivity. Its high gain and narrow beam make it suitable for wireless backhaul applications.

Does AF-5G34-S45 include a radio?

No. The AF-5G34-S45 is an antenna, while the compatible airFiber X radio is installed separately.

Is AF-5G34-S45 suitable for WISP networks?

Yes. The antenna is suitable for WISP tower backhaul, ISP infrastructure, building-to-building links, and other fixed wireless applications.

Where can I buy AF-5G34-S45 in Pakistan?

You can buy AF-5G34-S45 in Pakistan from professional networking equipment suppliers and online IT stores. Compare the latest AF-5G34-S45 price in Pakistan, warranty, availability, and radio compatibility before purchasing.
